ASRock 4Core1333-Viiv

LGA 775 for Intel® Core™ 2 Extreme / Core™ 2 Quad / Core™ 2 Duo / Pentium® Dual Core / Celeron®, supporting Quad Core Yorkfield and Dual Core Wolfdale processors Intel® P965 + ICH8DH Chipsets Intel® Viiv™ Ready Compatible with all FSB1333/1066/800/533MHz CPUs Supports Dual Channel DDR2 800/667/533 x 4 DIMM slots, with max. capacity up to 8GB Supports ATI™ CrossFire™ 1 x PCI Express x16 slot Additional AGI Express slot to adopt 2nd PCI Express x16 VGA card, and other PCI Express x4, x2, x1 interface cards Untied Overclocking : During Overclocking, FSB enjoys better margin due to fixed PCIE/ PCI Buses Hybrid Booster - Safe Overclocking Technology Supports Gigabit LAN 10/100/1000 Mb/s Supports 2 x IEEE 1394 ports (one port on back panel, one header on board) 6 x SATAII 3.0 Gb/s, support RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel® Matrix Storage), NCQ, AHCI and "Hot Plug" functions 1 x eSATAII 3.0 Gb/s (shared with 1 SATAII port), support NCQ, AHCI and "Hot Plug" functions 7.1 CH Windows® Vista™ Premium Level HD Audio (ALC888 Audio Codec) Windows® Vista™ Premium 2007 Logo Ready Supports Windows® XP Media Center Edition Free Bundle: 1 x ASRock DeskExpress, providing PCI Express slot for all kinds of PCI Express interface cards, and 1 Front USB port ASRock 1394_eSATAII I/O Plus: 1 eSATAII Port, 1 x IEEE 1394 Port, 4 ready-to-use USB Ports

Product Specifications

General
CPU	- LGA 775 for Intel® Core™ 2 Extreme / Core™ 2 Quad / Core™ 2 Duo / Pentium® Dual Core / Celeron®, supporting Quad Core Yorkfield and Dual Core Wolfdale processors - Compatible with all FSB1333*/1066/800/533MHz CPUs - Intel® Viiv™ Ready - Supports Hyper-Threading Technology - Supports Untied Overclocking Technology - Supports EM64T CPU *In overclocking mode.
Chipset	- Northbridge: Intel® P965 - Southbridge: Intel® ICH8DH
Memory	- Dual Channel DDR2 memory technology - 4 x DDR2 DIMM slots - Supports DDR2 800/667/533 non-ECC, un-buffered memory - Max. capacity of system memory: 8GB* *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® XP and Windows® Vista™. For Windows® XP 64-bit and Windows® Vista™ 64-bit with 64-bit CPU, there is no such limitation.
BIOS	- 4Mb AMI BIOS - AMI Legal BIOS - Supports "Plug and Play" - ACPI 1.1 Compliance Wake Up Events - Supports Jumperfree - SMBIOS 2.3.1 Support
Audio, Video and Networking
Graphics	- n/a
Audio	- 7.1 CH Windows® Vista™ Premium Level HD Audio (ALC888 Audio Codec)
LAN	- Gigabit LAN 10/100/1000 Mb/s - Giga PHY Intel® 82566DC - Supports Wake-On-LAN
Expansion / Connectivity
Slots	- Supports ATI™ CrossFire™ - 1 x PCI Express x16 slot - 1 x AGI Express slot (PCI Express x4) - 1 x PCI Express x1 slot - 3 x PCI slots
Connector	- 6 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 10, RAID 5 and Intel® Matrix Storage), NCQ, AHCI and "Hot Plug" functions - 1 x eSATAII 3.0 Gb/s connector (shared with 1 SATAII port), supports NCQ, AHCI and "Hot Plug" functions - 1 x ATA133 IDE connector (supports 2 x IDE devices) - 1 x Floppy connector - 1 x DeskExpress Hot Plug Detection header - 1x Game port header - 1 x HDMI_SPDIF header - 1 x IEEE 1394 header - CPU/Chassis FAN connector - 20 pin ATX power connector - 4 pin 12V power connector - SLI/XFire power connector - CD in header - Front panel audio connector - 3 x USB 2.0 headers (support 6 USB 2.0 ports)
Rear Panel I/O	ASRock 1394_eSATAII I/O Plus - 1 x PS/2 Mouse Port - 1 x PS/2 Keyboard Port - 1 x Serial Port: COM1 - 1 x Parallel Port (ECP/EPP support) - 4 x Ready-to-Use USB 2.0 Ports - 1 x eSATAII Port - 1 x RJ-45 LAN Port - 1 x IEEE 1394 Port - HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
Other Features / Miscellaneous
Unique Feature	Hybrid Booster: - CPU Frequency Stepless Control - ASRock U-COP - Boot Failure Guard (B.F.G.)
Support CD	- Drivers, Utilities, AntiVirus Software (Trial Version)
Accessories	- Quick Installation Guide, Support CD, I/O Shield - Floppy/ATA 133 Cables - 4 x SATA Data Cables (optional) - 1 x SATA 1 to 1 Power Cable (optional) - 1 x HDMI_SPDIF Cable (optional) - 1 x DeskExpress Hot Plug Detection Cable (optional) - 1 x USB Header Data Cable (optional) - 1 x ASRock DeskExpress (optional) - 1 x PCIE_DE Card (optional) - 4 x Screws (optional)
Hardware Monitor	- CPU Temperature Sensing - Chassis Temperature Sensing - CPU Fan Tachometer - Chassis Fan Tachometer - CPU Quiet Fan - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
Form Factor	- ATX Form Factor: 12.0-in x 9.0-in, 30.5 cm x 22.9 cm
OS	- Microsoft® Windows® 2000 / XP / XP Media Center / XP 64-bit / Vista™ / Vista™ 64-bit compliant
Certifications	- FCC, CE, WHQL
